Agreement with Vancouver Port Authority to Exchange Use of Optical Fibre Networks
RECOMMENDATION
THAT the General Manager of Corporate Services and the Director of Legal Services be authorized to negotiate, execute and deliver a licence agreement with the Vancouver Port Authority (the "VPA") for a fibre-swap which will permit the VPA and the City to each use 6 strands of the other's optical fibre network running between Canada Place and the E-Comm facility.
GENERAL MANAGER'S COMMENTS
The General Manager of Corporate Services RECOMMENDS approval.
COUNCIL POLICY
Execution of legal agreements by the Director of Legal Services and General Manager of Engineering Services with respect to access to City streets requires Council approval.
On July 30, 1996, when dealing with a report on Telecommunications Policies, Council approved a number of goals including one to ensure that the City maintains its authority to regulate equitable access to rights-of-way, secure valuable compensation for their use, minimize negative impacts associated with their use, and utilize them in a manner that furthers other telecommunications policy objectives.PURPOSE
The City and the Vancouver Port Authority (VPA) have parallel optical fibre data networks between the vicinity of Canada Place and the E-Comm facility. Providing each with the use of a limited number of the other's optical fibres minimizes the risk to both organizations of a single network failure impacting the accessibility of core information systems.
The purpose of this report is to ask Council to approve the City negotiating, executing and delivering a limited fibre-sharing agreement with VPA.
BACKGROUND
Optical fibre is the high-speed telecommunications medium of choice, with capacity far in excess of either conventional copper lines or wireless links. A typical configuration consists of silica fibres bonded together in ribbons of 6 fibres, with between 1 and 72 ribbons bundled into a protective sheath to form a cable of between 10 mm and 25 mm in diameter. In general, a pair of fibres is needed for each data connection.
The VPA has existing optical fibre running east-west along the south shore of Burrard Inlet, providing telecommunications services for data and security applications.
The City, through its duct licence agreements with Urban Networks Inc. (initially approved by Council on January 22, 2002 and an extension approved by Council on Feb 24, 2004), has an optical fibre network which includes a 48-fibre segment running east-west along Hastings Street from E-Comm through the downtown core.
In mid-2003, City staff asked VPA to consider an arrangement that was basically a fibre swap; it would provide the City with the use of a limited number of VPA fibres, and VPA with the use of the same number of City fibres. A common interest was identified, discussions continued, and an agreement in principle has been reached.
DISCUSSION
The City's core information and communication systems are located in the E-Comm facility to take advantage of its "hardening" against a variety of threats. These systems currently include e-mail, SAP, Internet/intranet, GIS, property document management and file storage. The long-term goal is that all systems will be located at this data centre, with a backup data centre at the Chess Street Fire Training Centre.
In order for staff (and the public, in some cases) to use these systems, data connectivity is needed. At present, a single optical fibre cable provides connectivity to the E-Comm data centre. This cable has redundant fibre pairs within it, so that if one fibre of a pair fails, another pair automatically takes over. However, the greatest threats to this data connection are either from construction activity (e.g. a backhoe) or from a localized ground fault (e.g. an earthquake). In either of these situations, the whole cable is likely to be damaged and the internal redundancy would be inadequate to protect against loss of connectivity.
A better approach is to have fibre redundancy through geographically distinct paths, which the VPA optical fibre offers. Under this scenario, the primary route to E-Comm would be through City fibre, while the secondary route would be through VPA fibre, with the converse being the case for VPA.
The proposed agreement may be summarized as:
· The City would give VPA the use of 6 fibres, and VPA would give the City the use of 6 fibres, both for a limited term;
· The extent of the exchange would span a point-to-point connection between Canada Place and a location on Cassiar Street close to the E-Comm building (see map in Appendix). The segment through VPA property will be referred to as the "north segment", that through City property as the "south segment";
· The City will be responsible for maintenance and repair of the south segment; VPA will be responsible for maintenance and repair of the north segment;
· The City will be responsible for costs (estimated at $15,000) of a small duct build from E-Comm to the Cassiar Control Room; VPA will be responsible for all costs of building duct and laying fibre on the north segment. These costs are estimated to be over $100,000;
· Both parties can use the swapped fibre only for their own, non-commercial business purposes and no third-party commercial use will be allowed, and
· Both parties will respect and protect the security and confidentiality of the other's data traffic.From the City's perspective, the benefits are significant:
· This route redundancy is essential to mitigate the risk of interrupted access to City systems and the impact on services should that happen;
· Speedy implementation can be expected;
· The cost of leasing a telecommunications line with the necessary capacity is estimated to be $60,000 a year,while the risk and costs are minimal:
· The $15,000 build of conduit between the E-Comm facility and the Cassiar Control Room not only enables this arrangement, it is a valuable addition to the City's duct infrastructure. Potential future benefits accrue from the interconnection between the City, VPA, E-Comm and Ministry of Transportation and Highways' (MoTH) duct systems and data networks for possible security, transportation and emergency response use, and
· The City will not lose any net network capacity - it will just be re-distributed;From VPA's perspective, the benefits are also significant, offering:
· The same degree of path redundancy;
· Access to E-Comm for integrated security, emergency response and disaster recovery purposes, and
· Access to the MoTH duct infrastructure.A joint application to the MoTH for a permit to use the MoTH duct system for part of the north segment that runs up the McGill Street on-ramp has been approved.
ALTERNATIVES/OPTIONS
The City could lease telecommunications service from a commercial provider. Given the relatively high capacity required, the annual cost of such a leased service is estimated to be $60,000.
The City could also build an alternate fibre route, most probably south from E-Comm down Renfrew and west along 41st, where it would interconnect with a new fibre segment on Ontario St. While the City may consider this option in the future, costs are estimated at $20,000 - $40,000 on top of the $15,000 E-Comm - Cassiar duct build (which would still be needed for complete independence of routes), and the time to deploy would be considerably longer.
The arrangement with VPA is preferable to either of these alternatives.
FINANCIAL IMPLICATIONS
On May 14, 2002, Council approved the recommendation of a report titled "Improvement to Information Technology Business Continuity Capabilities". This report recommended relocation of the City's key information servers to E-Comm, and identified associated annual telecommunications costs of $50,000, of which $40,000 was for the backup connectivity that this report proposes through the fibre swap. Starting in 2003, this was included in the Information Technology operating budget, though not used.
The estimated $15,000 cost of this initiative can be funded from the 2004 operating budget.
A $40,000 annual reduction in the Information Technology budget is projected, subject to review of the 2005 operating budget.
CONCLUSION
The proposed agreement with VPA mitigates a risk of major service disruption at little cost to the City. It permits an operating budget reduction, and offers the potential of improved communication between the City, the VPA, E-Comm and the MoTH, to the public benefit.
It is recommended that Council approve that the General Manager of Corporate Services and the Director of Legal Services be authorized to conclude an agreement with VPA with the goal of exchanging these optical fibres as soon as possible.
- - - - -
Appendix
CITY/VPA OPTICAL FIBRE ROUTES
* * * * *
